HP325 Compressors

Quick & effortless inflation power

Perfect for a multitude of air applications: air suspension, air horns, inflatables, flat tires & small air tools. 12 VDC & 24 VDC (Volts of Direct Current) air compressors are intended for filling air tanks for both the on and off-road markets.

HP325压缩机是适合使用空气助教nks up to 2.5 gallons.

HP325 Highlights

Universal Applications
Quick and effortless inflation power
HP325 SERIES - Our 1/4 HP AMP air compressors have a 33% duty cycle (20 minutes @ 100 psi) and are offered in both 12 and 24 VDC
All AMP compressors have a max working pressure of 150 psi and are an oil-less design
They contain sealed bearings, a PTFE piston ring & a copper wire wound permanent magnet motor

HP325 Compressor kits

Choose from premium kits and basic kits.

Onboard Air Application Guide

We're here to help.

Don't see the option you were looking for, or need help identifying your optimal solution? Contact Customer Support at 800.663.0096, available Monday - Friday 6:00am to 4:30pm PST orsubmit a support requestand we'll get back to you ASAP.

FIND A DEALER

HP325 Series Features & Benefits

12 VDC & 24 VDC (Volts of Direct Current) air compressors are intended for filling air tanks for both the on and off-road markets
These 1/4 horsepower compressors have an oil-less design, sealed bearings, PTFE piston ring, copper wire wound permanent magnet motor, a hard anodized aluminum cylinder sleeve and are equipped with a check valve to prevent possible motor damage
Mountable in any orientation.
33% Duty Cycle (20 minutes @ 100 PSI)
150 PSI Max Working Pressure
1.2 SCFM
8.7″ x 4″ x 6.2″ (LxWxH), 5.5 lbs
158°F Max /-40°F Ambient Temperature Range

The Premium Air HP325 Compressor Kit offers pre-built wiring harnesses for the ultimate ease of installation
Sealed bearings
Cast aluminum cylinder head
Hard anodized aluminum cylinder
PTFE piston ring
Mountable in any orientation
Basic kits are also available
